Testing Avro Serialization and Deserialization with Schema Registry in a Spring Boot Application

No bean overrides just serdes configuration

There are multiple ways to test Avro publication and consumption in a Spring Boot application.

For simplicity, this post will use the terms “serializer” and “serialization,” but the same principles apply to “deserializers” and “deserialization.”

Testcontainers #

An approach is to replicate your production environment using Testcontainers. You can spin up a Schema Registry container and connect to it in your tests.

However, this adds a fair amount of complexity and overhead, which can often be avoided while still giving you the confidence that your Avro serialization and deserialization work as expected, which is ultimately what you want to test.

MockSchemaRegistryClient implementation #

The kafka-schema-registry-client artifact provides us with a MockSchemaRegistryClient implementation of the SchemaRegistryClient. It works as a stub, keeping all schemas in memory.

How to wire the Mock impl. in your Spring-Boot application? #

There are numerous ways to let your Spring-Boot application make use of the MockSchemaRegistryClient.

Browsing through the source code you would find the following dependency hierarchy.

[SchemaRegistryClient]
       ▲
       │
[KafkaAvroSerializer]
       ▲
       │
[DefaultKafkaProducerFactory]
       ▲
       │
[KafkaTemplate]

The KafkaTemplate bean is autoconfigured by Spring-Boot and depends upon a ProducerFactory which on its turn requires a Serializer.

That Serializer in our case is the KafkaAvroSerializer which depends upon a SchemaRegistryClient.

Given that setup it only feels natural to use inversion of control to swap in a MockSchemaRegistry for tests and use a CachedSchemaRegistryClient elsewhere.

This works fine, but there’s a catch; if you create your own KafkaAvroSerializer, you’ll have to call its configure() method yourself, otherwise important serialization properties won’t be set.

And honestly, wiring all of this up by hand feels a bit silly in a Spring-Boot world where things are supposed to be auto-configured for you.

The way it was intended #

Actually to wire in a Mock implementation you do not need to rely on Spring-Boot as it is provided out of the box by the schema-registry client code.

All you have to do is configure your KafkaAvroSerializer with a schema.registry.url property that starts with mock://.

spring.kafka.properties.schema.registry.url: mock://

The above will make the KafkaAvroSerializer automatically use a MockSchemaRegistryClient.

How does mock:// work? #

As mentioned earlier, when configure() is called on the KafkaAvroSerializer (which happens automatically by the KafkaProducer), it ends up in SchemaRegistryClientFactory. That factory selects the impl. based upon the given URL as such:

String mockScope = MockSchemaRegistry.validateAndMaybeGetMockScope(baseUrls);
if (mockScope !=null){
    return MockSchemaRegistry.getClientForScope(mockScope, providers);
} else {
    return new CachedSchemaRegistryClient(...);
}

So no extra wiring, no manual serializer config, no hassle.

Mock scopes #

The mock:// URL can include a scope, which is a name that links a specific MockSchemaRegistryClient instance to a particular URL.

For example, mock://test will create a MockSchemaRegistryClient for the scope named “test”. Any other producer or consumer configured with the same mock://test URL will share this same client and its in-memory schemas.

Different scopes are useful for:

• simulating multiple Schema Registry instances
• isolating test scenarios
• avoiding conflicts in parallel tests

In most cases you can just use mock:// without a scope name, as it defaults to using an empty string ("") as the scope. This means all components configured with mock:// will also share the same MockSchemaRegistryClient instance.

A word on the placement of the schema.registry.url property #

There are basically 4 location where you can put the property and this goes for all serdes specific properties:

1. Global Kafka client properties #

Applied to all producers, consumers, and Kafka Streams clients.

spring.kafka.properties.schema.registry.url: mock://

2. Producer-only properties #

spring.kafka.producer.properties.schema.registry.url: mock://

3. Consumer-only properties #

spring.kafka.consumer.properties.schema.registry.url: mock://

4. Kafka-Stream-specific properties #

spring.kafka.streams.properties.schema.registry.url: mock://
