Putting a Kafka Topic Naming Convention into Practice with Terraform

From gentle suggestions to enforced rules.

Documented naming conventions are basically gentle suggestions until you enforce them in code. Whether a developer intentionally cuts corners, genuinely misunderstands the rules, or just makes a typo, human error is inevitable.

This article builds on a previous one where I introduced the idea of a topic naming convention.

A simple convention will be used as an example, but the principles apply to any convention. The goal is to show how to enforce a naming convention with Terraform.

The public topics have exactly four segments:

<environment>.<domain>.<subdomain>.<type>

The possible environments are dev, uat, and prd.
The possible domains are orders, inventory, and payments.
All characters are limited to lowercase letters and dashes.
The type is either event or state where state topics are compact with infinite retention.

Some examples:

prd.orders.checkout.event
dev.inventory.stock.state
prd.orders.refund.state

Application internal topics consist of:

<environment>.<type-of-service>.<app-name>[.<subject>]

Where type-of-service is one of: app (for domain applications), tool (for tools), connect (for kafka-connect).

Some examples:

dev.app.inventory-service.event
prd.connect.source-s3-billing

Even consumer groups can follow conventions, <environment>.app.<app-name>[.<consumer-group-name>].

Some examples:

dev.app.inventory-service
dev.app.inventory-service.api

The goal #


# The name of the service that owns the topics.
# Used to verify the internal topics naming and consumer group convention.
service_name = "inventory-service"

topics = [
  {
    name               = "${var.env}.inventory.stock.event"
    partitions         = var.partitions
    replication_factor = var.replication_factor
    retention_tier     = "long"
  },
  {
    name               = "${var.env}.inventory.stock.state"
    partitions         = var.partitions
    replication_factor = var.replication_factor
  },
  {
    name               = "${var.env}.app.inventory-service.belt"
    partitions         = var.partitions
    replication_factor = var.replication_factor
    retention_tier     = "short"
  },
]

consumer_groups = ["${var.env}.app.inventory-service"]

Step 1: Wrap the Kafka provider resources #

We will use the Mongey/kafka provider, but the confluentinc/confluent provider is also a good option. The wrapper module will be a thin layer that adds validation and governance rules.

variables.tf defines a custom convenience variable for the topics to be created.

variable "topics" {
  type = list(object({
    name               = string
    partitions         = number
    replication_factor = number
    config = optional(map(string), {})
  }))
}

main.tf will be responsible for creating the topics using the underlying module.

resource "kafka_topic" "this" {
  for_each = {for t in var.topics : t.name => t}

  name               = each.value.name
  partitions         = each.value.partitions
  replication_factor = each.value.replication_factor
  config             = each.value.config
}

Often overlooked yet extremely valuable is testing a module like this.

main.tftest.hcl:

mock_provider "kafka" {}

run "create_topic" {
  variables {
    topics = [
      {
        name               = "orders"
        partitions         = 6
        replication_factor = 3
        config = {
          "cleanup.policy" = "compact"
          "retention.ms"   = "604800000"
        }
      },
    ]
  }

  assert {
    condition     = length(kafka_topic.this) == 1
    error_message = "Expected exactly 1 topic to be created"
  }

  assert {
    condition     = kafka_topic.this["orders"].name == "orders"
    error_message = "orders topic name does not match"
  }

  assert {
    condition     = kafka_topic.this["orders"].partitions == 6
    error_message = "orders partitions does not match"
  }
  // more assertions in the example repo
}

Step 2: Add the validation rules #

The attentive reader will have noticed that the created topic orders in our tests does not follow the convention. Once the naming convention is validated, the test will fail with a clear message.

Maybe let’s add the tests first?

run "create_valid_topic" {
  variables {
    topics = [
      {
        name               = "prd.orders.checkout.event"
        partitions         = 6
        replication_factor = 3
        config = {
          "cleanup.policy" = "compact"
          "retention.ms"   = "604800000"
        }
      },
    ]
  }

  assert {
    condition     = length(kafka_topic.this) == 1
    error_message = "Expected exactly 1 topic to be created"
  }

  assert {
    condition     = kafka_topic.this["prd.orders.checkout.event"].name == "prd.orders.checkout.event"
    error_message = "topic name does not match"
  }
  // more assertions in the example repo
}

Now that we have a failing test, we can add the validation rules to the wrapper module.

variable "topics" {
  // previous code left out for brevity
  validation {
    condition = alltrue([
      for t in var.topics :
      can(regex("^(dev|uat|prd)\\.(orders|inventory|payments)\\.[a-z-]+\\.(event|state)$", t.name))
    ])
    error_message = "Topic name must follow the convention <env>.<domain>.<subdomain>.<type> where env ∈ {dev,uat,prd}, domain ∈ {orders,inventory,payments}, subdomain is lowercase letters/dashes, type ∈ {event,state}."
  }
}

Variable blocks can contain multiple validation blocks, so we can add more rules to enforce the other segments of the convention.

For example, imagine that we want to enforce that on PRD a minimum of 4 partitions is required.

variable "topics" {
  // previous code left out for brevity
  validation {
    condition = alltrue([
      for t in var.topics : can(regex("^prd\\.", t.name)) ? t.partitions >= 4 : true
      ])
    error_message = "Topics in PRD must have at least 4 partitions."
  }
}

Step 3: Add abstractions #

At times, it helps to add abstractions to the module to make it easier to use and avoid a hotchpotch of different settings. For example, we can introduce a retention_tier that abstracts away the retention.ms setting. Who knows how many ms one month is anyway? This also avoids having all kinds of scattered or incoherent retention policies.

locals {
  retention_tier_map = {
    short = "86400000"     # 1 day
    medium = "604800000"    # 7 days
    long = "2592000000"   # 30 days
    infinite = "-1"           # infinite retention
  }

  topic_configs = {
    for t in var.topics : t.name => merge(
        t.retention_tier != null ? { "retention.ms" = local.retention_tier_map[t.retention_tier] } : {},
      t.config,
        can(regex(".*\\.state$", t.name)) ? {
        "cleanup.policy" = "compact"
        "retention.ms"   = "-1"
      } : {},
    )
  }
}

And of course we can add a validation rule to ensure that the retention_tier is one of the allowed values and that config.retention.ms and retention_tier are mutually exclusive.

validation {
  condition = alltrue([
    for t in var.topics : t.retention_tier != null ? contains(["short", "medium", "long", "infinite"], t.retention_tier)
    : true
    ])
  error_message = "retention_tier must be one of: short, medium, long, infinite."
}

validation {
  condition = alltrue([
    for t in var.topics : !(t.retention_tier != null && can(t.config["retention.ms"]))
  ])
  error_message = "retention_tier and config.retention.ms are mutually exclusive, set only one."
}

Since the naming convention states that state topics are compact with infinite retention, we enforce that too. The merge order in topic_configs ensures .state topics always get cleanup.policy = "compact" and retention.ms = "-1", and validation blocks catch conflicting input early:

validation {
  condition = alltrue([
    for t in var.topics : can(regex(".*\\.state$", t.name)) && t.retention_tier != null ? t.retention_tier == "infinite"
    : true
    ])
  error_message = "State topics use infinite retention automatically — retention_tier must be 'infinite' or omitted."
}

validation {
  condition = alltrue([
    for t in var.topics : can(regex(".*\\.state$", t.name)) && can(t.config["retention.ms"]) ?
    t.config["retention.ms"] == "-1" : true
    ])
  error_message = "State topics use infinite retention automatically — config.retention.ms must be '-1' or omitted."
}

validation {
  condition = alltrue([
    for t in var.topics : can(regex(".*\\.state$", t.name)) && can(t.config["cleanup.policy"]) ?
    t.config["cleanup.policy"] == "compact" : true
    ])
  error_message = "State topics use cleanup.policy = compact automatically — config.cleanup.policy must be 'compact' or omitted."
}

The same abstraction principle applies to internal topic naming. A service_name variable lets callers declare their service name, and the module checks that internal topics follow the <env>.<type>.<app-name>[.<subject>] convention where type is app, tool, or connect:

variable "service_name" {
  type    = string
  default = null
  validation {
    condition     = var.service_name == null || can(regex("^[a-z-]+$", var.service_name))
    error_message = "service_name must be null or consist of lowercase letters and dashes only."
  }
}

service_name also enables consumer group management. When you pass a list of consumer group names via consumer_groups, the module creates kafka_acl resources with resource_type = "Group", granting Read access to User:<service_name>. This means naming and access control for consumer groups is handled alongside your topics.

By now you should have gotten the idea.

The full example module is available at https://github.com/jonas-grgt/kafka-conventions-demo-module.
