Kafka Testing Strategies with Spring

Table of Contents
How to test a spring based application that uses Kafka?
The goal of this post is to share my experience with testing a spring based application that uses Kafka. My aim has always been to have a fast feedback loop when testing my Kafka-based applications.
I will cover verifying that messages are published to Kafka, consuming them in tests.
A fully working example project accompanying this post can be found at:
https://github.com/jonas-grgt/spring-kafka-testing-demo
The system under test #
In this example, I will test a simple application that publishes a FraudSuspected
event.
@PostMapping("/creditcard/transactions")
void process(@RequestBody CreditCardTransaction transaction) {
if (transaction.amount() != null &&
transaction.amount().compareTo(new BigDecimal("10000")) >= 0) {
String fraudId = idGenerator.generateId();
kafkaTemplate.send(fraudAlertTopic, fraudId, FraudSuspected.newBuilder()
.setFraudId(fraudId)
.setSuspicionReason(SuspicionReason.UNUSUAL_AMOUNT)
.setAmount(transaction.amount())
.build());
}
}
Abstract away your topic configuration #
In one of my previous posts I emphasized having a topic naming convention. These fully qualified topic names can get long, convoluted and obnoxious to manage in your tests. In the beginning they can also be subjected to change and in that case I prefer to only have to define or change the topic in one place.
For example, when working with the dev.transactions.creditcard.fraud-alert.events
topic,
I never refer to it by its full name—I just call it the “fraud alert topic.”
So, I use configuration shorthand in my configuration:
my-app:
topics:
fraud-alert: ${env}.transactions.creditcard.fraud-alert.events
I aim for having one root application.yaml
and replace everything that differs per
environment, as I did with the env
variable above.
This way I can use the @Value
annotation to inject the topic —by reference— in my tests.
@Value("${my-app.topics.fraud-alert}")
String fraudAlertTopic;
The startup costs #
With the newer Kafka Native images, the container startup time has dropped significantly. That said, the Spring context initialization still tends to dominate the total test boot time. So optimizing how often that context is created becomes critical.
In my case for all integration tests I prefer to have one context to rule them all.
Sharing Testcontainers and Spring Contexts #
If you let your containers lifecycle be managed by Testcontainers, using the standard
@Testcontainers
and @Container
annotations, you will end up with a new Kafka container
for each test class.
This forces you to create a new Spring context for each test class as well since the
ConnectionDetails
will differ between tests.
To keep my test suite fast and lean, I optimize for:
- a single Spring context shared across all tests
- a single Kafka container reused by all test classes
Let me show you how I set that up.
Singleton containers managed by spring for the win #
When you expose a Container
as a Spring Bean, it will be started and stopped
automatically by Spring and be active for the lifetime of the application context—
as long as all the tests share the same Spring context.
@TestConfiguration(proxyBeanMethods = false)
class TestcontainersConfiguration {
@Bean
@ServiceConnection
KafkaContainer kafkaContainer() {
return new KafkaContainer("apache/kafka-native:3.8.0")
.withReuse(true)
.withExposedPorts(9092, 9093);
}
}
@SpringBootTest
@Import(TestcontainersConfiguration.class)
class MyKafkaTest {
// ...
}
Notice the @ServiceConnection
annotation, it binds the kafka connection details to
spring-boot’s configuration properties. In other words it will automatically set the
spring.kafka.bootstrap-servers
etc…
Verify records are published #
Consumer setup #
spring-kafka
comes with a handy utility class KafkaTestUtils
that allows us to consume
messages from a topic in a blocking way.
It either waits for an expected number of messages to be received or for a specific
timeout to be reached —default 60 seconds which is a bit too high for me.
It does require a KafkaConsumer
to be passed in. Luckily, we can leverage the
ConsumerFactory
that is already autoconfigured by spring-boot.
@Autowired
ConsumerFactory<String, Object> consumerFactory;
@Test
void myTest() {
this.consumer = consumerFactory.createConsumer("test-group", "-test-client");
this.consumer.subscribe(List.of(fraudAlertTopic));
ConsumerRecords<String, Object> records = KafkaTestUtils
.getRecords(this.consumer, Duration.ofSeconds(5));
}
Close the group before leaving the test #
Make sure to close the consumer at the end of your test. If you don’t, the group remains active, and the next test run using the same group ID will be slowed down due to a rejoin process.
During this delay, you’ll see a log message similar to the following:
[Consumer clientId=test.bank-test-client, groupId=test-group] (Re-)joining group
⚠️
Avoid closing the consumer group inside the test method, as it won’t run if the test fails
or is interrupted.
Instead, use an @AfterEach
method to ensure the consumer group is reliably closed after
each test.
For that you will need to assign it to an instance variable.
@AfterEach
void tearDown() {
if (this.consumer != null) {
this.consumer.close();
}
}
Randomize your group ID #
Alternatively, you can use a random group ID for each test to avoid the rejoin process.
This can be useful when you want to run tests in parallel or when your tests errors before
reaching the @AfterEach
method. Even with a random group ID, I would still opt to always
try to close the group.
Async timing issues #
Tests like these can be flaky if you’re not careful.
Async in nature #
The actual send to Kafka happens asynchronously, and may be batched depending on the
producer configuration.
The ListenableFuture
returned by KafkaTemplate
also reveals this async behavior.
If you want to force messages to be sent immediately, in a blocking manner, you can call:
kafkaTemplate.flush();
In any case, it’s usually better to embrace the asynchronous nature and use Awaitility to handle timing gracefully:
Awaitility.await()
.atMost(Duration.ofSeconds(5))
.untilAsserted(() -> {
ConsumerRecords<String, Object> records = KafkaTestUtils
.getRecords(this.consumer, Duration.ofMillis(200));
});
Note that the Duration
passed to getRecords
is shorter than the Awaitility timeout.
This way, if the records aren’t available yet, Awaitility will simply retry on the next poll.
Consumer Group Registration #
Kafka initial registration of a consumer group is when Consumer.poll()
is first called —
in our case from the KafkaTestUtils.getRecords()
method.
If a message is published before that call, and auto.offset.reset
is set to latest
(the default), the consumer will miss the record entirely.
This means that your first test will fail and subsequent tests might succeed depending on how they assert things.
To avoid this issue, I set the auto.offset.reset
property to earliest
in my
test application.yml
.
⚠️ Be careful when setting this property in your main or production
application.yml
as it will affect your production consumers.
spring:
kafka:
consumer:
properties:
auto-offset-reset: earliest
An alternative is to create a custom ConsumerFactory
for tests only and set the
auto.offset.reset
property there.
Lenient assertions #
Because I use the singleton Testcontainers approach, topics may contain leftover data from previous tests.
To avoid flaky tests, I rely on random ids and lenient assertions, meaning don’t blindly assert the exact number of messages received, but rather rely on specific ids or shape of the data to ensure you are asserting the records from your test.
Reusable TestContainers #
An added benefit of this approach is that I can reuse the container across test runs.
The container starts up once, and on subsequent runs it is reused with its existing state. In my case, this isn’t a problem—on the contrary, it helps speed things up.
To enable container reuse, I set the following in my ~/.testcontainers.properties
file:
testcontainers.reuse.enable=true
Final Test Example #
@SpringBootTest
@AutoConfigureMockMvc
@Import(TestcontainersConfiguration.class)
class FraudDetectionTests {
@Autowired
ConsumerFactory<String, Object> consumerFactory;
@Autowired
MockMvc mockMvc;
@Autowired
StubIdGenerator stubIdGenerator;
@Value("${bank.topics.fraud-alert}")
String fraudAlertTopic;
private Consumer<String, Object> consumer;
@AfterEach
void tearDown() {
if (this.consumer != null) {
this.consumer.close();
}
}
@Test
void fraudSuspectedWhenAmountIsUnusual() throws Exception {
// given
String fraudId = UUID.randomUUID().toString();
stubIdGenerator.setNextId(fraudId);
// when
mockMvc.perform(post("/creditcard/transactions")
.contentType(MediaType.APPLICATION_JSON)
.content("""
{
"amount": "10000.001"
}
"""))
.andExpect(status().isOk());
// then
this.consumer = consumerFactory.createConsumer("test-group", "-test-client");
this.consumer.subscribe(List.of(fraudAlertTopic));
Awaitility.await()
.atMost(Duration.ofSeconds(5))
.untilAsserted(() -> {
ConsumerRecords<String, Object> records = KafkaTestUtils
.getRecords(this.consumer, Duration.of(200));
assertThat(records)
.satisfiesOnlyOnce(record -> {
assertThat(record.key()).isEqualTo(fraudId);
assertThat(record.value())
.isInstanceOfSatisfying(FraudSuspected.class, c -> {
assertThat(c.getFraudId()).isEqualTo(fraudId);
assertThat(c.getAmount()).isPresent()
.get()
.usingComparator(BigDecimal::compareTo)
.isEqualTo(new BigDecimal("10000.001"));
assertThat(c.getSuspicionReason()).isEqualTo(UNUSUAL_AMOUNT);
});
});
});
}
}
Boilerplate #
I must admit that there is still some boilerplate code in the tests, something that I’ll abstract away in a follow-up post.
